 Beverage Filling Machine

Our company is a professional beverage machinery factory, the most advantageous products are beverage bottle filling machinebeverage can filling machinecarbonated beverage filling machinesmall beverage filling machine and high speed beverage filling machine.

Beverage machinery is a combination of three in one, the first part is washing,bottle clip equipped with efficient spray on nozzle.The extrusive droplet with 15 angleensures to wash all side of the bottle.The second part is filling,the filling valve material is SUS304.The filling system has liquid level automatic control.Filling valve elevator, after filling valve contact the bottle neck, it starts to fill.And the last part is capper,the magnetic torque is used foe screw capping.

The power of screw capping can be adjusted without steps.The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.

The product specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.

Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan\'s Mitsubishi, France Schneider, OMRON.

In order to make our products more competitive in the market, we guarantee the quality of our products, achieve reasonable prices, timely delivery, and have a good after-sales service system.



How Do Beverage Filling Machine Work?
Application Of Beverage Filling Machine
application5
Sachet Packing Machine​​​​​​​
This machine widely used to pack milk,soybean milk,sauce,vinegar,yellow wine,all kind of drink with film. The whole process can be accomplished automatically, such as ultraviolet sterilization,bag figuration,date printing,quantitative filling,enveloping,cutting,counting, and so on. The temperature of heat-sealing is controlled automatically, the production is beauty and fastness, the machine adopts stainless steel shell, and the sanitation is guaranteed.
​​​​​​​
application3fuben
Water Filling Machine​​​​​​​
This CGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled
mineral water, purified water,alcoholic beverage machinery and other non-gas beverage machinery.
The CGF Wash-filling-capping 3-in 1unit:Beverage Machinery can finish all the process such as press
bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.​​​​​​​
application2fuben
Juice Filling Machine
RCGF series drinking water filling machine integrates bottle washing, water filling and capping into one
 monobloc, and the three processws are carried out full automatically. Itis used in the hot filling of juice and tea beverage. It is equipped with perfect temmperature control system, reverse-flow system, automatic cleaning system and control program. Each machine element that grade rubber.​​​​​​​
application1fuben
5 Gallon Barrel Filling Machine​​​​​​​
This filling line specially for 3-5gallons barreled drink water, with type QGF-100, QGF-240, QGF-300, QGF-450, QGF-600, QGF-900, QGF-1200, It intergrates bottle washing, filling and capping into one unit, In order to achieve the purpose of washing and sterilizing, The washing machine use multi-washing liquid spray and-thimerosal spray, This thimerosal can be used circularly, The capping machine can cap barrel automatically , this line equips with water spraying device in order to ensure those caps sterilizer and clean.
application4
Oil Filling Mahicne​​​​​​​
1、Enhanced food safety: Stainless steel 304/316L for all components in contact with your beverage
2、Optimum uptime: 30 % reduction in changeover and maintenance downtime
3、Sustainable solution: Reduced filler enclosure and servomotors reduce resource consumption
4、Hygiene improvement through volume control and contactless filling
5、Automatic dummy bottles: Safer, easier cleaning procedures
6、Automatic bottle changeover improves uptime
application6
Can Filling Machine
1. The programmable controller automatically controls the entire process.
2. The PLC adopts German Siemens.
3. Use 7-inch touch screen.
4. Provide bottle type according to customers (330/500/1LPET/1.5LPET/1L tinplate, etc.)
5. All parameters can be modified without stopping.
6. Automatic control of the wine entering into the buffer tank of the filling machine and the CO2 backup pressure.

Specifications Of Beverage Filling Machine
透明水杯 Pure Water And Mineral
Water Treatment Plant

0.25-50tons/hr with RO system
矿泉水 Drinking Water Bottling Plant
2000BPH~36000BPH
PET Bottle: 200ml to 2000ml
400BPH~5000BPH
PET Bottle:3L to 7L
120BPH-2000BPH
PET Barrel: 10L to 5 Gallon
可乐 Carbonated Drink Bottling Plant
2000BPH~22000bph
PET Bottle: 200ml to 2000ml
果汁 Juice/Pulp Juice Bottling Plant
2000BPH~22000bph
PET Bottle: 200ml to 2000ml
啤酒 Beer, Vodka And Wine
Filling Machine

2000BPH~20000bph
Glass Bottle: 500ml
易拉罐 Can Filling Production Plant
2000BPH~20000bph
PET/ Aluminum Can: 330ml
菜籽油 Vegetable Oil Bottling Plant
1000BPH-2500bph
PET Bottle: 5000ml

3000BPH-10000bph
PET Bottle: 500ml
塑料瓶 PET Bottle Blow Molding
Machine

Semiautomatic type
1 cavity, 2 cavity, 4 cavity

Automatic type
2 cavity, 3 cavity, 4 cavity, 6 cavity and
8 cavity
注塑机 Injection Molding Machine
PET, PP, PVC, HDPE, LDPE, PC,
PA, PS, ABS

preform, cap, pvc pipe fittings and
connector, chair, bucket, basket,
spoon and other plastic products
汽油桶 Extrusion Blow Molding
Machine
PP, PE, PVC, PA, PS

Jerry Can, 5 Gallon Jar, bucket and
other plastic products
Model CGF14-12-5 CGF16-16-5 CGF24-24-8 CGF32-32-10 CGF40-40-12 CGF50-50-15
Capacity (BPH) 3000-5000 6000-8000 8000-12000 12000-15000 16000-20000 20000-24000
Power supply 2.42 KW 3.12 KW 3.92 KW 3.92 KW 5.87 KW 7.87 KW
Overall dimension 2360×1770×2700 2760×2060×2700 2800×2230×2700 3550×2650×2700 4700×3320×2700 7
Weight (KG) 2500 3500 4200 5500 6800 7600
Beverage Filling Machine Use Guide&Maintenance
How to maintain the liquid filling machine is not good. I'll teach you some tips for troubleshooting.
First of all, the machine can't start:
1. Turn on the power, turn on the power switch and check the fuse.
2. Release the emergency stop button.
3. Turn on the air pressure and keep it at about 6kg.
4. Check whether the switching power supply has DC24 V power output.
5. Check whether the communication line between touch screen and PLC is loose.
Secondly, the liquid filling machine does not discharge materials
1. Check the air pressure and the touch screen maintenance method.
2. Check whether the nozzle is closed and check the circuit.
3. Feed the liquid filling machine.
4. Check the air pressure, check whether the injection cylinder and cylinder are dead, check whether the blanking nozzle of the touch screen maintenance method screen is closed, and check the circuit.
Finally, the filling dose of liquid filling machine is forbidden
1. Check the feeding system of liquid filling machine.
2. Filter materials and clean pipes.
3. Replace the sealing ring of the pneumatic valve of the liquid filling machine, the air leakage of the air pipe, and replace the pneumatic valve.
4. Clean and replace the solenoid valve.
5. Clean and replace the silencing.
6. Adjust the ball valve to reduce the impact force and increase the diving depth.
7. Replace the O-ring of liquid filling machine.
8. Adjust the magnetic switch of injection cylinder.
Complete Beverage Filling Machine Line For Industry
Washing Part
1、Into bottle way is air conveyor direct connection with bottle dial.
2、All 304/316 stainless steel rinse heads, water spray style inject design, more save water consumption and more clean.
3、304/316 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing.
4、304/316 stainless steel washing pump make the machine more durable.
Filling Part
1、304/316 Stainless steel high precision filling nozzle
2、Filling volume adjustable in fine rank, same liquid level after filling
3、All 304/316 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
4、304/316 stainless steel filling pump
5、Efficient spray nozzle rinse thoroughly and save water for flushing
Capping Part
1、Place and capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping.
2、All 304/316 stainless steel construction
3、No bottle no capping
4、Automatic stop when lack of bottle
5、Capping effect is stable and reliable, Defective rate ≤0.2%
Flat convyer
1、Energy saving. High efficient. Adapt to customer factory layout
2、Special lubrication system, keep products clean, health, safety
3、Extended service life
4、Electric eyes design keep whole line running safety and quickly
5、Overload protection mechanism to effectively ensure the safety of the machine.
Beverage Filling Machine Brochure
Here is brochure of SKYM bervage filling machine products. You can find what you need from this brochre.

1. Water Filling Machine

Product Description

This CGF Wash-filling-capping 3-in-1unit:Beverage Machinery is used to produce polyester bottled mineral water, purified water, alcoholic beverage machinery and other non-gas beverage machinery. The CGF Wash-filling-capping 3-in-1unit:Beverage Machinery can finish all the process such as press bottle, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.

2

Rinser:

Bottle clip equipped with efficient spray on nozzle.The extrusive droplet with 15 angleensures to wash all side of the bottle.

3

Filler:

The filling valve material is SUS304.The filling system has liquid level automatic control.Filling valve elevator, after filling

valve contact the bottle neck, it starts to fill.

1

Capper:

The magnetic torque is used foe screw capping.The power of screw capping can be adjusted without steps.The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.

2. 3L5L Bottle Water Filling Machine

The LCGF4-4-1 machine adopts the principle is given liquid filling pressure filling. Main process is: cleaned the bottle into the bottle track wheel appropriated by the lift shaft parts, with the dial clockwise, the bottle filling valve from the bottom up and seal the bottle and realized the bottle sealed contact with the valve open Liquid cylinder of liquid in the downstream effects of its weight into the bottle, while the air inside the bottle of liquid in the shed, driven out from the center tube discharge valve, the liquid until the bottle vent pipe flooded the center, the irrigation Installed to stop, with the bottle down, filling valve closed, filling the bottle by the end of the bottle sealed track wheel output into the next process.

The main purpose and characteristics The filling machine is suitable for 3L To 5L pure water, mineral water and other non-automatic liquid filling gas, its main features are:

1 bottle red card is the bottleneck parts of method used, rotate 180 degrees, washing efficiency.

2, the use of fixed surface of the filling means filling quality, filling speed quickly.

3, the use of mechanicalliquid level automatic control mechanism.

4, filling valve, hydraulic cylinder and other parts of surface are in direct contact with high-quality stainless steel, corrosion-resistant, easy to clean, in line with industrial hygiene requirements.

5, the use of electromagnetic speed control motor, strong production capacity to achieve any adjustments.

6, compact structure, convenient operation and easy maintenance.

3. 5 Gallon Barrel Wtaer Filling Machine

SKYM Fully Automatic 5 Gallon Barrel Pure Mineral Water Filling Sealing Production Machine

QGF series 5 gallon filling machine is designed for producing 5 gallon barrel drinking water.This machine is consisted of rinser,filler and capper. The rinser has several sprays which can be used as for both clean water rinsing and disinfectant rinsing. The disinfectant can be recycled. The machine also has automatic capping device, and cap rinsing device. The whole production line can automatic feeding barrel, rinsing, sterilizing, filling, capping, counting and output.

QGF barrel production line is specially used for 5 Gallon barrel drinking water. This machine integrates washing/filling/capping into one unit. It is the good ideal for produce the mineral water/distilled water/pure water equipments. Whole machine are adopt the high quality stainless steel, It's erosion proof ability is strong, easy to washing.

4. Soft Drinking Filling Machine

DCGF-series rinsing, filling, Capping 3-in-1 monobloc machine introduced by foreign advanced gas-filling technique is a high performance fully automatic liquid packaging equipment.

Machine for carbonated beverage packaging machine has the following characteristics: filling tank, filling valves and other components in direct contact with the material are high-quality stainless steel or non-toxic materials, in line with food hygiene requirements: use of resistant seals hot rubber to meet the high-temperature sterilization process of user requirements: PCL programmable controller used to realize from the bottle into the machine to the packaging of finished using the automatic control of frequency control, easy to transfer the user to adjust prepared to meet the different process on the capacity requirements; using isobaric filling principle and popular spring-loaded valves, ensuring the quality of the beverage, using an advanced magnetic clutch adjustment screw cap torque device to ensure the quality of the blocks.

1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.

2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..

3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.

4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.

5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.

6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.

5. Sachet Filling Machine

50ml 330ml 500ml 1000ml Automatic Milk Juice Drinking Water Sachet Liquid Filling Packing Machine with Bags and date printer.

This series of liquid filling machine is widely used in the film packing of milk , soy milk , all kinds of drinks , soy vinegar ,yellow wine etc . All packing procedures including ultraviolet ray sterilization , molding of bags , print of dates , filling with fixed quantity , sealing and cutting and numeration , can finished at the same time,all components are made of stainless steels and are designed to meet national hygienic standard,C model adopt composite film.They are all can be designed middle sealing ,side sealing or photo-electric detection .Machine main structure is Stainless steel. suit for single layer film packing.

Sachet water filling line

This sachet filling machines are offered in models with photocell monitoring and without photocell monitoring. Photocell monitoring is used to fi

ll pouches with preprinted labels to ensure that all the bags are uniform in the placement of the logo on the bag. The model without photocell monitoring fills and packages the sachet to the same length and capacity, but is does not guarantee the logo on the bag is in the same placement across all bags.
